Electric-Actuator 220v-230v-24v-AC-DC-Brass-Ball-Motorized-Valve


1. Product Features

  • Material:Brass

  • Power: Solenoid

  • Media: Water

  • Port Size: 1/2"-1-1/4"

  • Structure: Ball

  • Driving mode :Electric/Manual,with Position indicator

  • PN Class :PN16

  • Valve characteristic :90°Rotary(ON-OFF Type)

  • Power supply :AC230V /24V AC

  • Torque :12 Nm

  • Running time :33~36 seconds

  • Valve platform :ISO5211(F03)

  • Shell material :ABS

  • Single gross weight :0.9 kg


2. Product photos

3. Product specification

Technical Data


Model

AQUA600-2/AQUA600-3

Driving mode

Electric/Manual,with Position indicator

PN Class

PN16

Valve characteristic

90°Rotary(ON-OFF Type)

Power supply

AC230V /24V AC

Protection grade

IP44

Torque

12 Nm

Running time

33~36 seconds

Shell material

ABS

Cable length

1.0 M x 4wires.


4. Product Description

This series of motorized ball valve is suitable for HVAC and status control of water system. Valve body is adopting ISO5211 standard platform, the actuator's using synchronous machine which drives the gears steady.
The new product is to be met the requirement of customers with compact size, large torque, simple operation and free maintenance, convenient for installation under different working conditions. In addition, the actuator is equipped with a manual handle, so it can open or close valve in case of the power cut or other emergency.


5. Huibo Certification

Huibo-valve-factory-certification

6. Production process

Huibo-valve-factory-brass-valve-technological-process

7. Huibo Factory

Huibo-valve-factory-brass-valve
