Brass Air Release Valve

Brass Air Release Valve

Body: Forging body and cap.
Surface: Brass plated nickel or natural color
Sealing: EPDM, PTFE or Teflon
Size: 3/8" to 1" (DN15-DN25)
Medium: water, oil

Send Inquiry

Forged brass air release valve for manifold

1. Product features and application
● Body: Forging body and cap.
● Surface: Brass plated nickel or natural color
● Sealing: EPDM, PTFE or Teflon
● Size: 3/8" to 1"(DN15-DN25)
● Medium: water, oil
● Working temperature:-20°C to 100°C
● Working pressure: Max 10bar
● Thread: PT. PF. NPT. G. BSP. NPS . BSPT
● Connection standard: PN10, PN16, BSPT and NPT male.
● Connection thread: NPT, BSPT



2. Material specifications of brass air release valve


NO.

Parts

Material

1

Body

Brass

2

Floating ball

Stainless steel 304

3

The lever

Stainless steel 304

4

The lever frame

Stainless steel 304

5

Stopper head

Synthetic rubber

6

AVAX

Brass



3. Dimensions of brass air release valve


DN

Spec(Inch)

L1(mm)

H1(mm)

L2(mm)

H2(mm)

Weight

3/8"

3/8"

47

113

102

127


1/2"

1/2"

47

113

102

127


3/4"

3/4"

47

113

102

127


1"

1"

47

113

102

127




4. Product introduction of brass air release valve
The brass air release valve is suitable for the heating air-condition system. It is used to protect and improve the efficiency of water delivery and save the energy. The brass air release should be installed at the commanding point or the elbow in order to exclude the unnecessary air in the pipe and improve the service efficiency of pipelines and save energy. In normal operation, such as pipeline will produce a small amount of natural gas will flock to the upper part of the tube, to a considerable extent, the brass air release valve, float down at any time discharge gas from the hole.


5. Certificate of product
Certificate of product.jpg
