Lockable Brass Gate Valve

Body material: Brass (HPb58-3)
Surface Color: Natural brass color
Size: 1/2"--1"
Nominal pressure: 2.0MPa
Working Temperature: -10ºC≤t≤120ºC

Send Inquiry

Lockable Brass Gate Valve with magnetic lock

1.Product features and application of lockable brass gate valve
● Body material: Brass (HPb58-3)
● Surface Color: Natural brass color
● Size: 1/2"--1"
● Nominal pressure: 2.0MPa
● Working Temperature: -10ºC≤t≤120ºC
● Connection way: female thread
● Cylindrical pipe thread: comply with ISO230, NPT, BSP
● Medium: Water, non-corrosive liquid, saturated steam(≤0.6MPa)
● Usage: industrial use, household use, home use, farming use
● Surface color: Brass color
● CSA approved
● Certificate: CE, SGS, ISO9001




Material specifications of lockable brass gate valve

NO.

Part Name

Material

1

Body

Brass

2

Wedge

Brass

3

Stem

Brass

4

Washer

PTFE

5

Bonnet

Brass

6

Screw Ring

Brass

7

Packing

PTFE

8

Gasket

Brass

9

Gland nut

Brass

10

Hand wheel

Aluminum

11

Washer

Aluminum

12

Lock nut

Iron


Dimensions of lockable brass gate valve

Spec(Inch)

B(mm)

H(mm)

L(mm)

E(mm)

Weight

1/2"

13.5

65

43

14


3/4"

13.5

70

48

19


1"

16

80

53

24



Product introduction of lockable brass gate valve
This lockable brass gate valve, with better wear resistance for smaller friction between the flap and sealing surface during valve opening and shut off. The height is only about 1/2 of the distance of the distance of the lockable brass gate valve seat when the lockable brass gate valve opened. Usually with only one sealing surface to assure good manufacturing technology and easy for using.
